Luus 2 Burner 300mm Griddle Cooktop - CS-2B3P

2 Burner 300mm Griddle Cooktop with flame failure, legs & shelf

Engineered to higher specifications, the CS-2B3P unit is a 600mm wide, compact high performance two burner cooktop with 300mm griddle. Available as a benchtop or freestanding with an undershelf storage area.

Key Features

• Open Burners
• • Nickel plated cast iron 28 mj dual-flame ring burners
• • Flame failure device standard (pilots optional extra)
• • Variable flame control valve with low flame setting
• • Heavy duty cast iron trivets
• • Pressed 0.7mm 304 stainless steel spillage bowls

• Griddle/Hotplate
• • 18 mj burners with pilot, FFD and piezo ignition
• • Variable flame control valve with low flame setting
• • 21mm thick mild steel griddle plate
• • Top weld sealed hotplate sections
• • CS-2B3P plate: 290mm x 540mm; 0.16m2 cooking area
• • 2mm 304 stainless steel splash guards

• Overall Construction
• • Heavy duty construction
• • Welded 1.2mm 304 stainless steel front hob
• • Front and side panels 0.9mm 304 stainless steel
• • Splashback 1.2 mm 304 stainless steel
• • Stainless steel legs with 55mm height adjustment range
• • Secondary catchment tray 0.9mm stainless steel

• Cleaning & Servicing
• • Removable burner hoods and spillage bowls
• • Secondary undertray to catch any additonal waste
• • Easy access to all parts & components from front

• Options/Accessories
• • Rear castors
• • Pilots to open burners
• • 300mm drop on plate (6mm mild steel) for open burners
• • Ribbed or chrome finish on hotplates
• • RH and LH side shields
• • Ceramic rocks (specify when ordering)
• • Benchtop mount (specify when ordering)

Specifications
